super cheap in-build Bypass Soft Starter 58USD
super cheap in-build Bypass Soft Starter 58USD
Couldn't load pickup availability
This soft starter is an advanced digital soft start solution suitable for motors with power ranging from 0.37kW to 115k. It provides a complete set of protections to motor and system, ensuring reliable performance even in the harshest installation environments.
Function list
Optional soft start curve
●Voltage ramp start
●Torque start
Optional soft stop curve
●Free parking
●Timed soft parking
Expanded input and output options
● Remote control input
● Relay output
● RS485 communication output
Easy to read display with comprehensive feedback
●Removable operation panel
●Built-in Chinese + English display
Customizable protection
●Input phase loss
●Output phase loss
●Running overload
●Starting overcurrent
●Running overcurrent
●Underload
Models that meet all connectivity requirements
● 0.37-115KW (rated)
● 220VAC-380VAC
●Star shaped connection
or inner triangle connection
| Terminal type | Terminal No. | Terminal name | Instruction |
| Main circuit | R,S,T | Power Input | Soft start three-phase AC power input |
| Main circuit | U,V,W | Soft Start Output | Connect three-phase asynchronous motor |
| Communication | A | RS485+ | For ModBusRTU communication |
| B | RS485- | ||
| Digital input | 12V | Public | 12V common |
| Digital input | |||
| Digital input | IN1 | start | Short connection with common terminal (12V) Startable soft start |
| Digital input | IN2 | Stop | Disconnect from the common terminal (12V) to stop and start soft start. |
| Digital input | IN3 | External Fault | Short-circuit with the common terminal (12V), soft start and shutdown |
| power supply output | A1 | AC220V | AC220V output |
| A2 | |||
| Programming Relay 1 | TA | Programming relay COM | Programmable Relay output, available to select following functions: No action; Power-on action; Soft start action; Bypass action; Soft stop action; Runtime actions; Standby action; Failure action; |
| Programming Relay 1 | TB | Programming relay normally close | |
| Programming Relay 1 | TC | Programming relay normally open |
warranty 1 years. we will provide whole life technical support. please inquiry us for shipping cost.
| Powere | Current A | Voltage V | Price(usd) |
| 5.5KW | 11A | 380V-480V | 58 |
| 7.5KW | 15A | 380V-480V | 62 |
| 11KW | 22A | 380V-480V | 72 |
| 15KW | 30A | 380V-480V | 77 |
| 18.5KW | 37A | 380V-480V | 96 |
| 22KW | 44A | 380V-480V | 103 |
| 30KW | 60A | 380V-480V | 108 |
| 37KW | 74A | 380V-480V | 115 |
| 45KW | 90A | 380V-480V | 132 |
| 55KW | 110A | 380V-480V | 144 |
| 75KW | 150A | 380V-480V | 168 |
| 90KW | 180A | 380V-480V | 360 |
| 115KW | 230A | 380V-480V | 432 |
